Форсунка PB84P30-001M PB84P30 YTO PB84P30-001M Амурдеталь Благовещенск

Описание

Характеристики

Форсунка PB84P30-001M PB84P30 Yto PB84P32

Injector BK.PB84P-32 BKPB84P32 PB84P-32

PB84P30-001M DSLA150P92032 YTO YT4A2-T55FS-1 Engine Parts Catalog

PB84P30001M DSLA150P920-32 YTO

PB84P30-001

PB84P30001

PB84P

Корпус BK.PB84P-32-001

nozzle BK.DSLA150P920-32 YTO YT4A2-T55FS-1 Engine Parts Catalog

序号 No.	零件名称	零件代号 DrawingNo.	数量 Qty.
1	Fuel injector	PB84P30-001M	4
1.1	Fuel injector housing	BK.PB84P-32-001	1
1.2	Regulating gasket	PB86J-00-029	1
1.3	Fuel injection valve spring	PB85PL-00-002A	1
1.4	Spring seat	PB85PL-00-006	1
1.5	Joint plate parts	PB85PL-00-010	1
1.6	Injector nozzle matching parts	BK.DSLA150P920-32	1
1.7	Fuel injector nut	BK.PB84P-00A-004	1
2	Fuel injector gasket	R320001-FE	4
3	Overflow pipe joint screw washer	R.320002-51	8
4	Spilled oil connection screws	42.19.110A	4
